This support load diagram outlines the point loads and linear weights for a material handling conveyor and scanner array system. The sortation conveyor is rated at 100 pounds per linear foot, while the queue conveyor carries 800 pounds per linear foot. The automatic tag reader exerts 500 pounds each, with its frame introducing four point loads of 125 pounds each. Point loads are based exclusively on the composite weight of the conveyor equipment, and the maintenance platform provides for an assumed live load of 500 pounds.
[250#] [250#] [250#] [250#] [215#] TYP. 2 PLACES EACH SIDE COMPONENT WEIGHT SORTATION CONVEYOR: 100#/LF QUEUE: CONVEYOR: 800#/LF AUTOMATIC TAG READER: 500# EA. MAINTENANCE PLATFORM: **NOTE NOTE: THE POINT LOADS REPRESENTED ARE BASED ON COMPOSITE WEIGHT OF CONVEYOR EQUIPMENT ONLY. TAG READER FRAME WITH 4 POINT LOAD OF [125#] EACH THE TAG READER MAINTENANCE PLATFORM SHALL PROVIDE FOR AN ASSUMED LIVE LOAD OF 500#. A T R
