An acoustical ceiling panel system integrates a sprinkler head pipe penetration featuring a one-inch-and-a-half escutcheon with a flange typically detailed at one inch from the pipe. The assembly includes the line of the ceiling runner beyond, with oversized holes omitted at sprinkler heads utilizing flexible fittings.
PIPE PENETRATION ACP CEILING SYSTEM LINE OF RUNNER BEYOND 1" 1" ESCUTCHEON WITH 1-1/2" FLANGE TYP 1 1/2" OVERSIZED HOLE NOT REQ @ SPRINKER HEADS W/ FLEXIBLE FITTINGS 6" = 1'-0" 17 ACP CEILING-CONCEALED SPRINKLER HEAD CLNG-ACOU-DF-17
