Paint color transitions are located at or adjacent to panel jambs, head, and sill conditions within panel reveals. All paint color transitions terminate at the full depth of the joint and or panel return.
PANEL FACE PANEL FACE REVEAL PAINT TRANSITION (AT OR ADJACENT HEAD) PAINT TRANSITION (AT OR ADJACENT JAMB) (TYP. HEAD OR SIM. CONDITION) (TYP. SILL OR SIM. CONDITION) NOTE: TERMINATE ALL PAINT COLOR TRANSITIONS AT THE FULL DEPTH OF THE JOINT AND/OR PANEL RETURN
