An aluminum curtain wall sill mullion bears upon a concrete floor slab adjacent to a stainless steel diffuser grate and drainage trench. A foil-faced self-adhered membrane runs beneath the sill assembly while a stainless steel flashing coordinates with silicone sealant and backer rod at the glass interface. Below-grade self-adhered waterproofing membrane and a drainage panel extend down the exterior face of the slab.
100' - 0" LEVEL 01 REFER TO LANDSCAPE FOR EXTERIOR CONDITION BELOW-GRADE SELF-ADHERED MEMBRANE, EXTEND MIN. 12" ALONG FACE OF SLAB 11" 1" CW GLASS ALUM CW SILL MULLION - LOBBY SST FLASHING DIM PT 4" LOBBY FLOOR FINISH 2" ALUM CW VERTICAL MULLION BEYOND 1' - 0" 1' - 0" SST DIFFUSER GRATE DRAINAGE PANEL FOIL-FACED SELF-ADHERED MEMBRANE SILICONE SEALANT AND BACKER ROD 1"
