A concrete-filled metal pan stair tread sits within a steel channel stringer. A typical steel angle bracket supports the tread assembly. A steel plate stringer ties into a metal angle support that is bolted directly to the concrete slab using anchor bolts.
2 1/2" STL CHANNEL STRINGER W/ CONC FILLED MTL PAN 05 51 00 METAL ANGLE SUPPORT BOLTED TO SLAB 05 51 00 PLATE STRINGER 3" STL ANGLE BRACKET SUPPORT FOR TREAD, TYP
