A premanufactured roof hatch sits atop a raised curb framed with three-inch minimum treated wood blocking over a painted metal deck. The curb perimeter is sealed with membrane flashing and a twenty-four gauge galvanized counterflashing with riveted and soldered corners. A six-inch by six-inch by sixteen-inch long eighteen gauge bent plate fastens the deck to the wood blocking, while continuous fire caulk runs along the perimeter underside. An aluminum ship's ladder extends down through the roof opening, paired with a safety railing and a zinc-plated chain with spring clips.
3" MIN. TREATED WOOD BLOCKING MEMBRANE FLASHING FASTENER 6"X6"X16" LONG 18 GA. BENT PLATE FASTENED TO DECK AND WD. BLOCKING PREMANUF. CURB/ ROOF HATCH ROOF OPENING REF. ROOF PLAN NOTE: PROVIDE SAFETY RAILING PER MANUFACTURER'S RECOMMENDATIONS FRAME W/ CAP FLASHING 3" MIN. ALUMINUM SHIP'S LADDER CONT. FIRE CAULK ALONG PERIMETER PTD. MTL DECK; RE: STRUCTURAL INSTALL ADDITIONAL PERIMETER ROOF FASTENING AS REQ. 24. GA. GAL. COUNTERFLASHING RIVET AND SOLDER CORNERS ZINC PLATED CHAIN WITH SPRING CLIPS ROOF HATCH
