The assembly details a stair intermediate landing transition with concrete-filled pan treads supported by the stair stringer. A structural tube provides landing support, noted as provided by the stair manufacturer. Dimensions indicate standard tread and riser geometry.
1" 11" LANDING SUPPORT BY STAIR MANUF. STAIR STRINGER
