The door frame top edge aligns with the masonry coursing, unless otherwise noted. Electrical devices are located relative to the door frame and masonry grid lines, with specific dimensions provided for centering devices within masonry units. The assembly maintains a six-inch offset from the door frame centerline for adjacent devices. All device locations are coordinated to ensure they are centered within the masonry block layout.
Text on the drawing
GRID GRID NOTE: REFER TO RULE 10 FOR TYPICAL NOTES. NOT DIMENSIONED AND LOCATED ADJACENT TO DOOR OR WINDOW IN MASONRY RULE 16 6" TYP 8" TYP 4' - 0" 3' - 8" 7' - 0" 8" TYP ALIGN TOP OF DOOR FRAME WITH MASONRY COURSING, UON DEVICE LOCATION IN MASONRY EQ EQ EQ EQ EQ EQ DEVICE DEVICE
