A 3-inch shaft partition assembly is framed with C-H steel studs and faced on one side with five-eighths-inch gypsum board and on the other with one-inch gypsum shaftliner panels. The partition carries a fire rating under UL assembly number U415 with a limiting height of 16 feet 1 inch and an STC rating to be determined. Head and base connection details are referenced to sheet A8.01.
09 2116 GYPSUM SHAFTLINER PANEL 5/8" STC RATING : FIRE RATING : LIMITING HEIGHT : HEAD DETAIL : BASE DETAIL : S1JA SHAFT PARTITION TBD UL# U415 16'-1" 13 / A8.01 9 / A8.01 09 2900 GYPSUM BOARD 09 2116 C-H STEEL STUD 09 2116 C-H STEEL STUD 1" 3"
