A steel stair stringer connects to a finished wall surface with precast concrete treads and steel plate tread supports. Continuous backer rod and joint sealant are specified at the stringer-to-wall interface, maintaining a half-inch joint. Joint sealant is also applied at the top and bottom of the stringer. Where a ceiling occurs, the assembly incorporates five-eighths inch painted gypsum board and a half-inch aluminum reveal.
WALL SURFACE PRECAST CONC. TREAD SEALANT, TOP AND BOTTOM OF STRINGER 5/8" GYP. BOARD, PAINTED, WHERE CEILING OCCURS STEEL STRINGER 1/2" 1/2" ALUMINUM REVEAL WHERE CEILING OCCURS STEEL PLATE TREAD SUPPORT 1/2" CONT BACKER ROD & JOINT SEALANT 2"
