An interior storefront glazing system connects perpendicularly to a partition wall framed with three and five-eighths inch metal studs finished with gypsum board on both sides. A bead of sealant is applied at the junction between the storefront frame and the gypsum board face. The assembly divides an office space, conference room, and open work area.
I N T E R I O R S T O R E F R O N T G L A Z I N G S Y S T E M S E A L A N T O F F I C E O P E N W O R K A R E A C O N F E R E N C E R M P A R I T I O N W A L L ; G Y P B D O N 3 5 / 8 " M T L S T U D S
