A 1 1/2-inch solid surface counter with an eased edge rests upon a plastic laminate finish applied over a 3/4-inch MDF substrate. An LED light strip is recessed beneath the counter overhang, coordinated with electrical requirements. The vertical wall assembly features a plastic laminate finish on a 1/2-inch MDF substrate, accented by a 1/2-inch resin panel secured with stainless steel fasteners.
1 1/2" SOLID SURFACE COUNTER WITH EASED EDGE 1/2" RESIN PANEL WITH STAINLESS STEEL FASTENERS 3/4" 1/2" 1 1/4" 1" 3/4" PLASTIC LAMINATE FINISH ON3/4" MDF SUBSTRATE PLASTIC LAMINATE FINISH ON 1/2" MDF SUBSTRATE LED LIGHT STRIP - RE: ELECTRICAL
