Perforated metal panels on Z-clips mount over a two-hour rated stair enclosure surrounding a prefabricated stair with standard handrail. A two-hour rated ceiling and fire-rated underside bound the enclosure assembly. Elevation dimensions and level markers establish the vertical placement of the stair tube elements.
MZ 112' - 6" PERFORATED METAL PANEL ON Z-CLIPS OVER 2-HOUR RATED STAIR ENCLOSURE PREFABRICATED STAIR WITH STANDARD HANDRAIL 2-HOUR RATED CEILING FIRE RATED UNDERSIDE 2-HOUR RATED UNDERSIDE OF STAIR 1 " 1 "
