A-KKMXP — Roof Detail - Roof Drain

Architectural · A-KKMXP

Roof Detail - Roof Drain

Scale: 3" = 1'-0"
Units: imperial
Sheet: A7.34
Discipline: Architectural

Materials

Composite Concrete Membrane / Roofing Metal (misc.)Steel

Elements

Anchors / Embeds Connections / Plates Decks Drainage Insulation Roofs Waterproofing / Flashing

Connections

Deck Attachment

Text on the drawing

COVER BOARD DRAIN STRAINER RIGID ROOF INSULATION - TAPER 24" MIN FROM CENTER OF DRAIN METAL ROOF DECK - INCLUDES CONCRETE FILL INDICATED BY TYPE WATERSTOP/SEALANT PER ROOFING MFR DETAILS MEMBRANE ROOFING LAP MEMBRANE INTO ROOF DRAIN FASTENER AND PLATE (4) MIN MEMBRANE FLASHING MEMBRANE ROOFING
