A six-foot-high welded wire mesh screen partition is supported by a continuous steel angle secured to the concrete slab below. The one-and-a-half by one-and-a-half by one-eighth-inch steel angle is shot pinned to the concrete on three sides and to the hollow structural section at the top side of the partition. A four by six by three-eighth-inch HSS member runs above and connects via shot pins to the steel angle.
1 1/2" X 1 1/2" X 1/8" STL ANGLE SHOT PINNED TO CONCRETE AT (3) SIDES AND HSS AT TOP SIDE OF PARTITION 4" X 6" X 3/8" HSS ABOVE SHOT PIN TO STL ANGLE 6'-0" HIGH WELDED WIRE MESH SCREEN PARTITION
