A-KJV4E — Horizontal Subgirt Fastening to HSS Member at Noise Barrier Wall

Architectural · A-KJV4E

Horizontal Subgirt Fastening to HSS Member at Noise Barrier Wall

Materials

Steel Metal (misc.)

Elements

Columns Walls Roofs

Connections

About this detail

A horizontal subgirt fastens to a horizontal hollow structural section measuring 10x6 by the metal roof screen manufacturer. A noise barrier wall system fastens to the inside face of the mechanical area, utilizing a Kinetics Noiseblock or similar assembly.

A8.35 15 NOISE BARRIER WALL SYSTEM FASTEN TO INSIDE FACE OF MECHANICAL AREA (KINETICS NOISEBLOCK OR SIMILAR) HORIZ HSS 10X6, SSD HORIZ. SUBGIRT FASTEN TO HSS BY METAL ROOF SCREEN MANUFACTURER
