A-KGYQA — 2nd / 3rd Flr Column, 8, C (East Stair)

Architectural · A-KGYQA

2nd / 3rd Flr Column, 8, C (East Stair)

Scale: 1 1/2" = 1'-0"
Units: imperial
Sheet: A5.06
Discipline: Architectural

Materials

Cold-formed Steel Metal (misc.)Steel Timber / Wood

Elements

Columns Connections / Plates Partitions Stairs Walls

Text on the drawing

C C 8 8 EW2 S1A 0 3 S5A 2 33 EW4 S1A 0 3 STAIR S270 MEN'S RESTROOM 272 MAILROOM / HUDDLE CONTROL 241 1 HR PROTECTION AT EXTERIOR WALL (ADJACENT TO STAIR ENCLOSURE) TAB ATTACHED TO COLUMN FOR MTL STUD ATTACHMENT FIRE-PROOFED COLUMN
