A-KGY5Z — Wall Sconce Detail

Architectural · A-KGY5Z

Wall Sconce Detail

Scale: SCALE: 1 1/2" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

Cold-formed Steel Composite Masonry / CMU Stainless Steel Steel Timber / Wood

Elements

Facades / Cladding Walls Waterproofing / Flashing

Text on the drawing

UD CMU BLOCK LIGHT FIXTURE; RE: ELECTRICAL 7/8" HAT CHANNEL CAULK JOINTS UD 1 X SYNTHETIC WOOD CANT 4'-0" LONG TYPICAL WITH 1/2" BETWEEN LENGTHS CEMENT FIBER LAP SIDING STAINLESS STEEL FLASHING SHEET WATER BARRIER CEMENT FIBER LAP SIDING ELECTRICAL BACK BOX

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
