A steel pipe guardrail and handrail transition assembly is positioned at the interior face of a stair enclosure. The top and bottom rails and posts are constructed from one and a quarter inch nominal pipe size steel pipe. Handrail intersections are radiused typically, maintaining a one and a half inch unobstructed clearance at transitions. A bent closure plate anchors the base of the posts. Vertical dimensions indicate a three-foot guardrail height and a three-foot six-inch overall height.
3' - 0" 1 1/2" BENT CLOSURE PLATE HANDRAIL SHALL MAINTAIN A 1 1/2" UNOBSTRUCTED CLEARANCE AT TRANSITIONS (TYP) 1 1/4" (NPS) STL PIPE GUARDRAIL TOP AND BOTTOM RAILS AND POSTS 1 1/4" (NPS) STL PIPE HANDRAIL INTERSECTIONS RADIUSED (TYP) 3' - 6" INTERIOR FACE OF STAIR ENCLOSURE
