A one and one-half inch outer diameter stainless steel pipe handrail is mounted thirty-six inches above the stair nosing. The handrail connects to a three-eighths inch diameter painted steel rod handrail bracket with a one-inch radius curve. The bracket is welded to both the pipe and the stanchion, with the welds ground smooth and painted.
CL R=1" 1 1/2" EQ EQ 4" 1 1/2" O.D. SST PIPE HANDRAIL, MOUNT 36" ABOVE STAIR NOSING 3/8" DIA. PTD. STL. ROD HANDRAIL BRACKET WELD BRACKET TO PIPE AND STANCHION, GRIND SMOOTH AND PAINT Full Depth Partial Pen 1 1/2" O.D. SST PIPE HANDRAIL, MOUNT 36" 6" = 1'-0" 11 TYP. GUARD MOUNTED HANDRAIL BRACKET
