A compression strut post connects to a concrete deck using a 4-inch by 4-inch by 68-mil bent plate secured by two number 10 sheet metal screws. The assembly anchors to the concrete deck using a Hilti X-DNI shot pin with 1-inch embedment, maintaining a three-quarters-inch minimum clearance.
4"x4"x 68 MIL BENT PLATE (2) #10 SMS, TYP. COMPRESSION/STRUT POST 3/4" MIN AT CONC. DECK: HILTI X- DNI SHOT PIN W/ 1" EMBEDMENT
