This wall assembly is framed with six-inch cold-formed metal studs with stud spacing coordinated per structural drawings. The exterior side features one-half-inch gypsum sheathing. The interior side is finished with five-eighths-inch gypsum board and a specified wall finish per the finish schedule. Sound attenuation batt insulation is installed within the stud cavity.
INTERIOR SIDE 6" METAL STUD FRAMING. SEE STRUCTURAL DRAWINGS FOR STUD SPACING EXTERIOR SIDE 5/8" GYP. BD. 1/2" GYPSUM SHEATHING WALL FINISH, SEE FINISH SCHEDULE SOUND ATTENUATION BATT INSULATION
