Safety markings are installed on wall-mounted obstacles with a minimum height of six feet six inches above the finished floor. Optional wall-mounted demarcation lines run horizontally along the wall base, set as close as practical with clearances ranging from one to two inches.
MIN 6'-6" AFF MARKINGS OF OBSTACLES WALL MOUNTED DEMARCATION LINES (OPTIONAL) 1" MIN 2" MAX AS CLOSE AS PRACTICAL 1" MIN 2" MAX
