A-KEHMN — Quick Coupler in Box Detail

Architectural · A-KEHMN

Quick Coupler in Box Detail

About this detail

A Rain Bird 44NP quick coupling valve is housed inside a ten-inch round plastic valve box with a bolt-down lid, positioned flush with the finish grade. The valve connects to a vertical schedule 80 PVC nipple supported by a one-inch by twenty-four-inch angle iron with two hose clamps. The assembly ties into a PVC mainline via schedule 80 PVC fittings, nipples, and tees. The bottom of the box is filled with four inches of pea gravel, with a minimum twelve-inch clearance to walks, curbs, or headers, and two total bricks for support.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
