A typical cold-formed steel stud of size and gauge as required connects to a track of matching size and gauge. An end clip of size and gauge as required secures the stud web to the track flange. A fastener as required anchors the track assembly to the concrete substrate.
AS REQUIRED AS REQUIRED TYPICAL STUD, SIZE AND GAGE AS REQUIRED END CLIP, SIZE AND GAGE AS REQUIRED TYPICAL TRACK, SIZE AND GAGE AS REQUIRED FASTENER AS REQUIRED
