The parapet wall consists of a painted metal cap matching the adjacent wall, mounted over a framed wall assembly with an exterior insulation finish system on the exterior face. The roof assembly transitions at the parapet base with single-ply roofing over rigid insulation, concrete over a metal deck, supported by a structural steel beam below. Single-ply roofing also extends up the interior side of the framing wall.
H-4 T.O.P. 58'-6" AH12.3g 6 EXTERIOR INTERIOR SINGLE-PLY ROOFING OVER RIGID INSULATION OVER CONCRETE OVER METAL DECK SINGLE-PLY ROOFING OVER FRAMING WALL PAINTED METAL CAP TO MATCH ADJACENT WALL STEEL BEAM EXTERIOR INSULATION FINISH SYSTEM OVER FRAMED WALL
