A C-channel track frames into a double king stud assembly spaced at sixteen inches on center. A straight clip fastens the channel using two number ten screws, with the channel tab trimmed and bent in the field as required. The framing supports two-by studs running vertically alongside the track connection.
SILL DETAIL 2X STUDS @ 16" O.C. DOUBLE KING STUD STRAIGHT CLIP WITH (2) #10 SCREWS TRIM & BEND TAB OF CHANNEL IN FIELD AS REQUIRED, CONNECT TO STUD WITH #10 SCREWS C-CHANNEL TRACK
