A-KD9DJ — Plan Detail - Frameless

Architectural · A-KD9DJ

Plan Detail - Frameless

Scale: 3" = 1'-0"
Units: imperial
Sheet: A-731
Discipline: Architectural

Materials

Glass / Glazing Stainless Steel Steel

Elements

Storefronts Waterproofing / Flashing Windows

Text on the drawing

SCHEDULED GLAZING B.S. ALIGN ALIGN STAINLESS STEEL JAMB CHANNEL WITH NEOPRENE SPACER FLEXIBLE SEALANT INTERIOR EXT TILE ASSEMBLY PER A-401

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
