A scheduled door and frame assembly transitions from a tile floor to an adjacent concrete floor. The tile floor consists of a mortar bed over a crack suppression membrane supported by the concrete slab. An anodized aluminum transition strip, such as Schluter-Systems Reno-U or an approved equal, bridges the height difference between the tile finish and the concrete floor. The assembly sits directly on the concrete floor substrate.
SCHEDULED DOOR AND FRAME ASSEMBLY SCHEDULED TILE FLOOR MORTAR BED AND CRACK SUPPRESSION MEMBRANE SCHLUTER SYSTEMS RENO-U ANNODIZED ALUMINUM TRANSITION STRIP, OR APPROVED EQUAL. CONCRETE FLOOR
