A 1 1/2-inch by 2 1/2-inch steel top rail and a 1 1/2-inch diameter handrail mount to double 1/2-inch by 2-inch steel plate vertical supports. Eleven equally spaced horizontal cables span between the vertical supports. The vertical support anchors into an HSS stringer below a concrete floor slab. A storefront mullion sits on the concrete floor with sealant and backer rod on both sides, backed by a 24 gauge painted metal sheet flashing.
T.O. CONC. FLOOR 3 3/4" 3" 3'-6". 2'-11" 11 EQ. SPACED CABLE RAILING TYP. 1 1/2"x 2 1/2" STEEL TOP RAIL FACE OF CEMENT PLASTER WALL BEYOND ALUM. CURTAIN WALL 1 1/2" DIA. HANDRAIL DBL. 1/2" x2" STEEL PLATE VERTICAL SUPPORT 6" 3". HSS STRINGER 3'-0 1/8" 2" STOREFRONT MULLION SEALANT/ BACKER ROD AT BOTH SIDES 24 GA. METAL SHEET FLASHING PAINTED TO MATCH STOREFRONT MULLIONS
