Architectural · A-K6FV2

Typical Sign Attachment

Materials

Timber / Wood

Elements

Insulation Anchors / Embeds Reinforcing

Connections

Bolted Connection Embed Plate

About this detail

An exterior sign fixture mounts to building framing and internal wood blocking through an exterior insulation and finish system. The assembly consists of framing, an approved substrate, expanded polystyrene insulation board adhered with a base coat, reinforcing mesh embedded in a second base coat, and an exterior finish. A non-corrosive pipe sleeve is set in sealant through the layers to receive the attachment hardware. The sign fixture is secured with a screw or bolt and a neoprene washer, finished with a compatible sealant and bond breaker tape at the perimeter.
