A one-and-one-half-inch standard weight painted steel pipe handrail mounts to the face of a wall maintaining a one-and-one-half-inch clearance. Handrail brackets secure the assembly at a maximum spacing of four feet six inches on center typical.
FACE OF WALL 1 1/2" STD. WCT. STEEL PIPE HANDRAIL, PAINTED HANDRAIL BRACKETS @ 4'-6" O.C. MAX. TYP. 1 1/2"
