An exterior 90-degree metal panel corner assembly features a synthetic sheet air and water barrier applied over the backup wall. Concealed metal panel clips secure the panels while maintaining a typical three-eighths-inch joint width. The corner condition utilizes a compression corner detail for the ninety-degree bend with panel widths sized per elevations.
SYNTHETIC SHEET AIR/WATER BARRIER CONCEALED METAL PANEL CLIP METAL PANEL SYSTEM, COMPRESSION CORNER FOR 90 DEGREE BEND, TYP 3/8" TYP 3/8" REF ELEVS PANEL WIDTH REF ELEVS PANEL WIDTH
