The cabinet is secured to a metal stud wall assembly with minimum 193/256-inch clearance using steel wall brackets measuring 4 1/2 inches by 1 1/2 inches by 3/8 inches minimum. Two number 12 sheet metal screws secure each bracket to the backing, with four total per cabinet. Metal stud backing is provided at each attachment point per structural drawings. Two number 12 by 1-inch wood screws fasten each bracket to the cabinet, totaling four per cabinet.
METAL STUD BACKING PER SF5.20 @ EA. ATTACHMENT POINT NO. 12 SMS (2) PER BRACKET (4) PER CABINET STEEL WALL BRACKET 4 1/2" x 1 1/2" x 3/8" MIN (2) PER CABINET. MTL STUD WALL PER PLAN MIN. 193/256" NO. 12 X 1" WOOD SCREW. (2) PER BRACKET (4) PER CABINET
