A two-piece stainless steel cover plate is anchored by countersunk stainless steel fasteners into an L-profile steel frame at the floor transition. The assembly interfaces with a curtain wall system and a shade guide located beyond. Clearances and dimensions include one-quarter inch, one inch, two inches, one and a half inches, and four and seven-sixteenths inches.
SECTION C SHADE GUIDE BEYOND CURTAINWALL, SEE SCHEDULE 2 PIECE STAINLESS STEEL COVER PLATE COUNTERSUNK STAINLESS STEEL FASTENER L-PROFILE STEEL FRAME FF 1" 2" 1/4" 1/4" 1 1/2" 4 7/16"
