An intermediate floor level anchorage connects the aluminum curtain wall system to the concrete floor slab. A structural steel embed plate mounts to the slab face using four expansion or cast-in anchors. An adjustable steel bracket with a slotted vertical hole and bolted connection extends from the embed plate to the mullion. Vertical alignment is maintained with a two-inch gap between the top of the slab and the underside of the horizontal framing member, and a seven-inch dimension governs the anchor placement.
