The unit entry threshold detail shows an ADA-compliant aluminum threshold fastened over the floor assembly with countersunk fasteners flush to the top of the threshold. A Remko 234AV door shoe or approved equal is installed at the bottom of the entry door. The floor assembly matches the finish schedule and abuts the threshold transition. The head condition for the unit entry door is shown with a door frame beyond and the door sized per the schedule. Fastener heads are countersunk flush with the top of the threshold.
