Characters and background of signs feature a non-glare finish with distinct contrast to each other, using a standard white on blue background unless approved otherwise, and distinctly contrasting with the wall color. Sans-serif uppercase characters are raised 1/32 inch per local applicable accessibility standards, with character spacing and height maintaining 135% minimum and 170% maximum of character height. Corresponding Grade 2 braille is provided below the text per local applicable accessibility standards.
