A-JW2TE — Wall Sconce Detail

Architectural · A-JW2TE

Wall Sconce Detail

Scale: SCALE: 1 1/2" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

Cold-formed Steel Composite Masonry / CMU Stainless Steel Steel Timber / Wood

Elements

Facades / Cladding Walls Waterproofing / Flashing

Text on the drawing

UD CMU BLOCK LIGHT FIXTURE; RE: ELECTRICAL 7/8" HAT CHANNEL CAULK JOINTS UD 1 X SYNTHETIC WOOD CANT 4'-0" LONG TYPICAL WITH 1/2" BETWEEN LENGTHS CEMENT FIBER LAP SIDING STAINLESS STEEL FLASHING SHEET WATER BARRIER CEMENT FIBER LAP SIDING ELECTRICAL BACK BOX
