A cold-formed steel stud of size and gauge as required connects to a typical track of size and gauge as required using an end clip of size and gauge as required. The track is anchored to the concrete deck using powder-actuated fasteners spaced at 16 inches on center, supplemented by additional fasteners as required.
AS REQUIRED AS REQUIRED TYPICAL STUD, SIZE AND GAGE AS REQUIRED END CLIP, SIZE AND GAGE AS REQUIRED TYPICAL TRACK, SIZE AND GAGE AS REQUIRED FASTENER AS REQUIRED POWDER ACTUADED FASTENERS 16" O.C.
