Architectural · A-JTRXV

Elevator Door Frame Head Detail at Gypsum Board Wall

Materials

Elements

About this detail

An elevator door frame anchors to a framed wall assembly consisting of twenty-five gauge J-tracks, type X gypsum board, and one-inch gypsum liner panels. Cavity insulation fills the stud space typical of shaftwall conditions. Jamb anchor clips secure the frame assembly to the surrounding construction.
