A threaded rod drop hangs from an overhead structural connection utilizing a channel stiffener to reinforce the vertical support assembly. The threaded rod extends downward and secures a horizontal support member using nuts and washers. This attachment method is installed above the ceiling plane to support suspended architectural or MEP systems.
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
