A shaftwall system features a labelled door frame and a control joint assembly. The shaftwall is constructed with one-inch Type X gypsum board liner panels, sound batt insulation, and two layers of five-eighths-inch Type X gypsum board fastened with one-and-five-eighths-inch Type S screws spaced at twelve inches on center into USG steel J-runners. A position indicator box is mounted at the door frame assembly, utilizing full-height gypsum board liner panels. The control joint detail incorporates a half-inch joint sealed with sealant and backed by sound batt insulation between the gypsum layers.
SEALANT SOUND BATT INSULATION (2) LAYERS OF 5/8" GYPSUM BOARD TYPE X CONTROL JOINT SEALANT USG STEEL J- RUNNER 1" GYPSUM BOARD LINER PANELS TYPE X 1/2" JOINT USG STEEL J-RUNNER LABELLED DOOR FRAME (2) LAYERS OF 5/8" GYPSUM BOARD TYPE X POSITION INDICATOR BOX 1" GYP. BD. LINER PANEL FULL HEIGHT OF DOOR SYSTEM SHAFTWALL 4" MIN. 1 5/8" TYPE S SCREWS @ 12" O.C. 1" GYPSUM BOARD LINER PANELS TYPE X
