A three-eighths-inch terrazzo floor finish is applied over a concrete topping slab supported by a concrete structural slab. A crack isolation membrane is installed beneath the topping slab with a divider strip extending through the finish layer.
CONCRETE STRUCTURAL SLAB CONCRETE TOPPING SLAB CRACK ISOLATION MEMBRANE DIVIDER STRIP 3/ 8" TERRAZZO FLOOR
