Text on the drawing
W12 STEEL GIRT (REF STRUC) 3x5 STEEL ANGLE (REF STRUC) PREFINISHED HEAD TRIM INSULATED-CORE METAL WALL PANELS 4" 32'-8" OR 51'-0" GIRT ELEVATION 50'-8" STACK JOINT BEYOND (REF 11/A501)
