A one-inch thick gypsum shaft liner is backed by a six by twelve inch minimum twenty-five gauge steel strip centered on the device. This steel strip is installed only behind boxes where face panels are cut and removed. An additional one-inch gypsum liner box protection measuring at least four inches minimum width is applied over the assembly.
4" MIN. 1" GYP LINER BOX PROTECTION, 6" X 12" MIN. - INSTALL ONLY BEHIND BOXES WHERE FACE PANELS ARE CUT & REMOVED 6" X 12" MIN. 25 GA. STEEL STRIP CENTERED ON DEVICE 1" GYP SHAFT LINER
