A sixteen-gauge stainless steel fascia panel clads a structural steel beam detailed per structural drawings. A continuous stainless steel vapor retarder tapes to the face of the beam. Continuous sealant runs all around the joint. Stainless steel rivets fasten the assembly at six inches on center maximum with a two-inch dimension.
DP PER STRUC, SST CONT VAPOR RETARDER, TAPE TO FACE OF BEAM BEAM, PER STRUC FASCIA PANEL, 16 GA, SST RIVET AT 6" OC MAX RE: FASCIA W/ NO TB FOR DETAILS NOT SHOWN CONT SEALANT ALL AROUND 1'-3" 2"
