A-JPHK8 — Note: All Fixtures To Be In Line And

Architectural · A-JPHK8

Note: All Fixtures To Be In Line And

Materials

Gypsum / Drywall

Elements

About this detail

Ceiling fixtures including light fixtures, louvers, sprinkler heads, and speakers are arranged in a straight line with equal spacing dimensions unless noted otherwise. A centerline coordinates the layout of circular elements and a rectangular ceiling penetration. All fixtures must remain in line and centered in the field unless noted otherwise.

EQUAL EQUAL LIGHT FIXTURES, LOUVERS, SPRINKLER HEADS, SPEAKERS, ROOF HATCHED, ETC. IN LINE NOTE: ALL FIXTURES TO BE IN LINE AND CENTERED IN FIELD U.N.O.
