This exterior wall assembly consists of cement plaster applied over a drainage panel and an air barrier supported by exterior gypsum sheathing. The core structure is framed with six-inch metal studs containing six-inch batt insulation within the cavity. The interior side is finished with gypsum board, which is omitted at specific locations per detail E03. All layers are tied together to provide a continuous thermal and moisture envelope.
OMIT AT EXTERIOR INTERIOR E04 EXTERIOR STUCCO - WITH INTERIOR FINISH E03 EXTERIOR STUCCO - NO INTERIOR FINISH E03 CEMENT PLASTER DRAINAGE PANEL GYPSUM BOARD 6" BATT INSULATION 6" METAL FRAMING EXTERIOR GYPSUM SHEATHING AIR BARRIER
