Enlarged Z-Bracket Detail for Fire Extinguisher Cabinet

Materials

Concrete

Elements

Columns Walls Railings / Guards Parapets Millwork / Casework Anchors / Embeds

Connections

Embed Plate

About this detail

Mounting arrangement of a fire extinguisher cabinet attached to a concrete parapet crash wall via four Z-brackets. The brackets mount to the concrete column using screw fasteners on one flange and secure to the fire extinguisher cabinet using sheet metal screws on the other. A cable railing runs beyond the assembly, and the brackets are positioned to mount between and through the horizontal cable railing members. The cabinet is positioned with its handle at a maximum height of forty-two inches, and the entire assembly is coordinated with adjacent signage.
